CPR-DE-6018 / CPPS-350-12
2015
2919
Not specified
Specifications |
|||
|---|---|---|---|
| Coil Weight | 6000 pounds |
||
| Coil Width | 12 inches |
||
| Coil Thickness | .170 inches |
||
|
Coe Press Double End Coil Reel and 12 inch Capacity Coe Straightener Stock thickness capacity: .170" x 12" Wide
Stock thickness capacity: .187" x 08" Wide (85,000 PSI)
Stock thickness capacity: .250" x 03" Wide (85,000 PSI)
Coe Press Equipment Coil Feed Line Line Consisting of:
Coe Press Double End Coil Reel Model No. CPR-DE-PO-60
Three lead mandrel - hydraulic mandrel expansion
Adjustable coil keeper arms
Air brake for adjustable tensioning (fail safe)
Powered threading drive (jog)
Powered turret indexing for double end reel
Dual coil hold down arms with motorized end wheels
Coil hold up arm for run side mandrel
Coe Press Powered Coil Straightener Model No. CPPS-350-12
Seven straightening rolls x 3.5" diameter
Digital roll position indicators
Hand crank self centering edge guides
Pinch rolls x five inch diameter w/ air operated open / close
Stock peeler and threading station with motorized roll
AC Variable frequency drive (10 HP)
Operator's control station
Auto / run cycle w/ laser loop control
Coe Press Exit Threading Table Model No CPTT-12
12" Wide x 20' Long
Air operated actuation
Bomb-bay door design
Optional:
New or used servo roll feed to complete the line - consult sales for pricing
Upgrade your metal stamping and coil processing operations with this heavy-duty, used 2011 COE Press Double End Coil Reel and Straightener Combination Line (Model CPR-DE-PO-60 / CPPS-350-12). Engineered for high-efficiency feeding, this high-capacity uncoiler and power straightener handles up to 6,000 lbs. coil weight with a 12-inch stock width capacity, 72-inch max coil outer diameter, and up to 0.250" stock thickness capability. Packed with premium features, the double-ended reel includes a 3-lead hydraulic mandrel expansion, powered turret indexing, dual motorized coil hold-down arms, and an air brake for seamless loading and reduced downtime. The integrated 7-roll powered coil straightener offers digital roll position indicators, self-centering edge guides, an AC variable frequency drive with laser loop control, and a stock peeler station for effortless threading—paired with a COE CPTT-12 exit threading table. Contact sales today to inquire about this versatile COE coil handling equipment or to pair it with an optional servo roll feed for a turnkey coil processing line. |
|||
